SMPS(일반,방수) 상품리스트

SMPS(일반,방수)

제품 특징

범용 입력 85~260VAC / 저전력 소비 / 승인 : KC, EMI / 보호 : 과부하, 과전압, 단락

Product Model	DC Output	Load Regul.	R&N	Efficiency
A-15NR-12	12V	±1%	300mVp-p	78%
A-15NR-24	24V	±1%	300mVp-p	80%
A-35FAL-12	12V	±0.5%	150mVp-p	85%
A-35FAL-24	24V	±0.5%	200mVp-p	87%
A-50FAL-12	12V	±0.5%	250mVp-p	85%
A-50FAL-24	24V	±0.5%	250mVp-p	87%
A-75FAM-12	12V	±1%	150mVp-p	87%
A-75FAM-24	24V	±0.5%	200mVp-p	89%
A-100FAN-12	12V	±1%	150mVp-p	87%
A-100FAN-24	24V	±1%	200mVp-p	89%
A-150FAO-12	12V	±1%	150mVp-p	87%
A-150FAO-24	24V	±1%	200mVp-p	89%
A-200FAK-12	12V	±1%	150mVp-p	87%
A-200FAK-24	24V	±1%	150mVp-p	89%
A-350FAK-12	12V	±1%	150mVp-p	86%
A-350FAK-24	24V	±1%	150mVp-p	88%

Product Model	Pdf	Check	Detail
A-15NR-12			보기
A-15NR-24			보기
A-35FAL-12			보기
A-35FAL-24			보기
A-50FAL-12			보기
A-50FAL-24			보기
A-75FAM-12			보기
A-75FAM-24			보기
A-100FAN-12			보기
A-100FAN-24			보기
A-150FAO-12			보기
A-150FAO-24			보기
A-200FAK-12			보기
A-200FAK-24			보기
A-350FAK-12			보기
A-350FAK-24			보기

SMPS(일반,방수)

제품 특징

범용 입력 85~260VAC / 저전력 소비 / 승인 : KC, EMI / 보호 : 과부하, 과전압, 단락

Product Model	DC Output	Load Regul.	R&N	Efficiency
UP60S12W2(V1)	12V	±2%	170mVp-p	83%
UP60S12W2L	12V	±2%	600mVp-p	92%
UP60S24W2(V1)	24V	±2%	290mVp-p	85%
UP60S24W2L	24V	±2%	600mVp-p	92%
UP100S12W2L	12V	±2%	600mVp-p	91%
UP100S24W2L	24V	±2%	600mVp-p	92%
UP150S12W2L	12V	±2%	600mVp-p	92%
UP150S24W2L	24V	±2%	600mVp-p	93%

Product Model	Pdf	Check	Detail
UP60S12W2(V1)			보기
UP60S12W2L			보기
UP60S24W2(V1)			보기
UP60S24W2L			보기
UP100S12W2L			보기
UP100S24W2L			보기
UP150S12W2L			보기
UP150S24W2L			보기

SMPS(일반,방수)

제품 특징

범용 입력 85~260VAC / 저전력 소비 / 승인 : KC, EMI / 보호 : 과부하, 과전압, 단락

Product Model	DC Output	Load Regul.	R&N	Efficiency
UP60S12W2LM	12V	±2%	600mVp-p	92%
UP60S24W2LM	24V	±2%	600mVp-p	92%
UP100S12W2LM	12V	±2%	600mVp-p	91%
UP100S24W2LM	24V	±2%	600mVp-p	92%
UP150S12W2LM	12V	±2%	600mVp-p	91%
UP150S24W2LM	24V	±2%	600mVp-p	92%
UP200S12W2L	12V	±2%	1000mVp-p	91%
UP200S24W2L	24V	±2%	1000mVp-p	92%
UP300S12W2L	12V	±2%	1000mVp-p	91%
UP300S24W2L	24V	±2%	1000mVp-p	92%
UP400S12W2L	12V	±2%	1000mVp-p	91%
UP400S24W2L	24V	±2%	1000mVp-p	92%
UP500S12W2L	12V	±2%	1000mVp-p	92%
UP500S24W2L	24V	±2%	1000mVp-p	93%

Product Model	Pdf	Check	Detail
UP60S12W2LM			보기
UP60S24W2LM			보기
UP100S12W2LM			보기
UP100S24W2LM			보기
UP150S12W2LM			보기
UP150S24W2LM			보기
UP200S12W2L			보기
UP200S24W2L			보기
UP300S12W2L			보기
UP300S24W2L			보기
UP400S12W2L			보기
UP400S24W2L			보기
UP500S12W2L			보기
UP500S24W2L			보기

SMPS(일반,방수)

제품 특징

범용 입력 85~260VAC / 저전력 소비 / 승인 : KC, EMI / 보호 : 과부하, 과전압, 단락

Product Model	DC Output	R&N	Efficiency
UPF100S12WQ2	12V	150mVp-p	85%
UPF150S12WQ2	12V	150mVp-p	86%
UPF200S12WQ2	12V	150mVp-p	88%
UPF300S12WQ2	12V	150mVp-p	89%

Product Model	Pdf	Check	Detail
UPF100S12WQ2			보기
UPF150S12WQ2			보기
UPF200S12WQ2			보기
UPF300S12WQ2			보기

SMPS(일반,방수)

제품 특징

범용 입력 85~260VAC / 저전력 소비 / 승인 : KC, EMI, PSE / 보호 : 과부하, 과전압, 단락

Product Model	DC Output	R&N	Efficiency
UPF100S12WQ	12V	150mVp-p	86%
UPF100S24WQ	24V	150mVp-p	87%
UPF150S12WQ	12V	150mVp-p	89%
UPF150S24WQ	24V	150mVp-p	90%
UPF200S12WQ	12V	150mVp-p	89%
UPF200S24WQ	24V	150mVp-p	90%
UPF300S12WQ	12V	150mVp-p	90%
UPF300S24WQ	24V	150mVp-p	92%

Product Model	Pdf	Check	Detail
UPF100S12WQ			보기
UPF100S24WQ			보기
UPF150S12WQ			보기
UPF150S24WQ			보기
UPF200S12WQ			보기
UPF200S24WQ			보기
UPF300S12WQ			보기
UPF300S24WQ			보기

SMPS(일반,방수)

제품 특징

범용 입력 85~260VAC / 저전력 소비 / 승인 : KC, EMI, PSE / 보호 : 과부하, 과전압, 단락

Product Model	DC Output	R&N	Efficiency
UPF30S36CQHP	36V	3Vp-p	85%
UPF30S36CQH	36V	2Vp-p	85%
UPF30S48CQH	48V	2Vp-p	86%
UPF40S12CQH	12V	150mVp-p	84%
UPF40S24CQH	24V	150mVp-p	85%
UPF40S36CQH	36V	150mVp-p	85%
UPF40S48CQH	48V	150mVp-p	87%
UPF60S12CQH	12V	150mVp-p	84%
UPF60S24CQH	24V	150mVp-p	86%
UPF60S36CQH	36V	150mVp-p	86%
UPF60S48CQH	48V	150mVp-p	88%
UPF80S12CQH	12V	150mVp-p	85%
UPF80S24CQH	24V	150mVp-p	87%
UPF80S36CQH	36V	150mVp-p	88%
UPF80S48CQH	48V	150mVp-p	89%

Product Model	Pdf	Check	Detail
UPF30S36CQHP			보기
UPF30S36CQH			보기
UPF30S48CQH			보기
UPF40S12CQH			보기
UPF40S24CQH			보기
UPF40S36CQH			보기
UPF40S48CQH			보기
UPF60S12CQH			보기
UPF60S24CQH			보기
UPF60S36CQH			보기
UPF60S48CQH			보기
UPF80S12CQH			보기
UPF80S24CQH			보기
UPF80S36CQH			보기
UPF80S48CQH			보기
